Male Run Tee

Male Run Tee

IMPERIAL RANGE - DIMENSIONS IN INCHES

T O/D	P	Ax LENGTH	B	Hy	F	G NUT	Hx BODY	H	A
1/8	1/8	1.00	0.38	0.76	0.47	7/16	0.72	1.48	1.76
1/8	1/4	1.00	0.56	0.94	0.47	7/16	0.72	1.66	1.94
3/16	1/8	1.00	0.38	0.76	0.47	1/2	0.75	1.51	1.76
1/4	1/8	1.07	0.38	0.76	0.47	9/16	0.78	1.54	1.83
1/4	1/4	1.07	0.56	0.94	0.47	9/16	0.78	1.72	2.01
5/16	1/8	1.16	0.38	0.82	0.55	5/8	0.87	1.70	1.98
3/8	1/4	1.21	0.56	1.00	0.55	11/16	0.91	1.91	2.21
1/2	3/8	1.38	0.56	1.08	0.74	7/8	0.98	2.06	2.46
1/2	1/2	1.38	0.75	1.26	0.74	7/8	0.98	2.24	2.64
5/8	1/2	1.47	0.75	1.38	0.74	1	1.06	2.40	2.85

METRIC RANGE - DIMENSIONS IN INCHES

T O/D	P	Ax LENGTH	B	Hy	F	G NUT	Hx BODY	H	A
4	1/16	26.15	9.53	19.30	12	12	19.05	38.10	45.45
4	1/8	26.15	9.53	19.30	12	12	19.05	38.10	45.45
4	1/4	26.15	14.29	23.88	12	12	19.05	38.10	50.03
6	1/8	27.21	9.53	19.30	12	14	19.81	39.62	46.51
6	1/4	27.21	14.29	23.88	12	14	19.81	39.62	51.09
6	3/8	28.74	14.29	25.40	14	14	21.34	42.68	54.14
6	1/2	30.51	19.05	32.00	19	14	23.11	43.22	62.51
8	1/8	29.73	9.53	20.83	14	17	22.23	44.46	50.56
8	1/4	29.73	14.29	25.40	14	17	22.23	44.46	55.13
8	3/8	29.73	14.29	25.40	14	17	22.23	44.46	55.13
8	1/2	31.50	19.05	32.00	19	17	24.00	48.00	63.50
10	1/8	30.81	9.53	20.83	14	19	23.11	46.22	51.64
10	1/4	30.81	14.29	25.40	14	19	23.11	46.22	56.21
10	3/8	30.81	14.29	25.40	14	19	23.11	46.22	56.21
10	1/2	32.59	19.05	32.00	19	19	24.89	49.78	64.59
12	1/4	34.99	14.29	27.43	19	22	24.89	49.78	62.42
12	3/8	34.99	14.29	27.43	19	22	24.89	49.78	62.42
12	1/2	34.99	19.05	32.00	19	22	24.89	49.78	66.99
16	1/2	36.39	19.05	34.30	24	27	26.19	52.38	71.32
